True-Bypass Switching Circuit
True bypass means that when the effect
is off your guitar tone will not be affected at all. The true bypass
circuit makes sure you have
absolutely no tone loss or signal reduction
through the choruspedal in the off/bypass mode. This switch makes sure you have absolutely no tone loss or signal reduction
through the chours even in the off mode.
SPECIFICATIONS:
Input impedance: approx. 400K
Output impedance: approx. 2K
Current consumption: 40mA at 9VDC
DC supply voltage range: 9 VDC
True-Bypass Switching Circuit
True bypass means that when the effect is off your guitar tone will not
be affected at all. The true bypass circuit makes sure you have
absolutely no tone loss or signal reduction
through the choruspedal in the off/bypass mode. This switch makes sure you have absolutely no tone loss or signal reduction
through the chours even in the off mode.
Dimensions (L/W/H): 94(L)MM x 39(W)MM x 32(H)MM
Power: 9VDC, Negative Tips (Regulated recommended) (not included)
Weight: 165g
Package included:
only the pedal
