Shenzhen Grand Technology Co., Ltd
All items guaranteed 100% BRAND NEW in the original edition Box.
ONE-YEAR WARRANTY !!!
Specifications:
Output power: 18W X2 (A)
Output impedance: 4Ω, 8Ω
Input voltage: 300mV
M M input voltage: 3mV
Distortion ≤0.8%
Signal to noise ratio: 92dB
Frequency response: 18HZ—50KHZ ±1DB
Input selection : 3 groups
Output selection : 2 groups
Power consumption: 190W
Magnification tube: KT90 (special) x2, 5Z3/5U4G x1, 6SN7 (special) x2, 5687 x1, 12AX7x1, US GE5670 x2
Power supply voltage: AC110/220V 60Hz/50Hz (100V,110V,120V, 230V, 240V version will take 3-14 work days to order), 220V version is in stock
Net Weight: 17kg
Gross weight: 19kg
Features and features:
1. Pure manual point-to-point soldering circuit, durable.
2. Made of Japanese Z11 silicon steel sheet as EI power transformer and output transformer, ensuring good stability and musical performance.
3. Use a special KT90 Class A circuit to output dual-channel 18W, electronic tube rectification, to ensure a high degree of reproduction of the amplified tone, beautiful and pleasant.
4. A dual-purpose machine, is not only an excellent Class A amplifier, but also a high-quality phono amplifier, from the turntable audio input to the power amplifier to directly drive the speakers, a machine to complete. Convenient and practical, cost-effective.
5. Phono LP (mm) sings the effect: The sound field is vivid, the resolution is clear, the harmonics are rich, and the bottomless noise is.
