TUBE KT90 CLASS A SINGLE-END INTERGRATED AMPLIFIER+PHONO LP MM

All items guaranteed 100% BRAND NEW in the original edition Box.

ONE-YEAR WARRANTY !!!

Specifications:

Output power: 18W X2 (A)

Output impedance: 4Ω, 8Ω

Input voltage: 300mV

M M input voltage: 3mV

Distortion ≤0.8%

Signal to noise ratio: 92dB

Frequency response: 18HZ—50KHZ ±1DB

Input selection : 3 groups

Output selection : 2 groups

Power consumption: 190W

Magnification tube: KT90 (special) x2, 5Z3/5U4G x1, 6SN7 (special) x2, 5687 x1, 12AX7x1, US GE5670 x2

Power supply voltage: AC110/220V 60Hz/50Hz (100V,110V，120V, 230V, 240V version will take 3-14 work days to order), 220V version is in stock

Net Weight: 17kg

Gross weight: 19kg

Features and features:

1. Pure manual point-to-point soldering circuit, durable.

2. Made of Japanese Z11 silicon steel sheet as EI power transformer and output transformer, ensuring good stability and musical performance.

3. Use a special KT90 Class A circuit to output dual-channel 18W, electronic tube rectification, to ensure a high degree of reproduction of the amplified tone, beautiful and pleasant.

4. A dual-purpose machine, is not only an excellent Class A amplifier, but also a high-quality phono amplifier, from the turntable audio input to the power amplifier to directly drive the speakers, a machine to complete. Convenient and practical, cost-effective.

5. Phono LP (mm) sings the effect: The sound field is vivid, the resolution is clear, the harmonics are rich, and the bottomless noise is.
